Photocells for FAAC XP20B D gates

Description

FAAC XP20B D photocells are advanced devices designed to secure automatic entrance and garage gates. Known for their reliability and high-quality workmanship, these photocells offer users full safety and comfort of use.

Features and benefits:

1. Modern detection technology:
   • FAAC XP20B D are equipped with precise infrared sensors that effectively detect obstacles in the gate's path to prevent accidental collisions.
2. Simple and quick installation:
   • The mounting system has been designed with ease of use in mind to enable quick and intuitive mounting of photocells on various surfaces.
3. High resistance to weather conditions:
   • FAAC XP20B D photocells are resistant to unfavorable weather conditions, such as rain, snow or extreme temperatures, which ensures their reliable operation all year round.
4. Compact and elegant design:
   • The slim and modern casing of the photocells makes them perfectly match the aesthetics of the gates, without affecting their appearance.
5. Compliance with safety standards:
   • The device meets rigorous safety standards, which is confirmed by appropriate certificates. Automatic stopping of the gate movement when an obstacle is detected protects both people and property.

Technical Specifications:

• Model: FAAC XP20B D
• Detection range: up to 20 meters
• Supply voltage range: 12-24V AC/DC
• Output Signal Type: NO/NC (Normally Open/Close)
• Level of security: IP54
• Working temperature: -20°C to +55°C

Application:

FAAC XP20B D photocells are ideal for a wide range of applications in gate automation systems. They are perfect for entrance gates, garage gates, industrial gates and other places requiring a high level of security and protection against unauthorized access.

Instructions for use:

1. Installation:
   • Install photocells on stable surfaces, opposite each other, so that they are at the optimal height for detecting obstacles.
   • Connect the device to the power supply and gate control system in accordance with the attached instructions.
2. Configuration:
   • Adjust operating parameters using available switches to meet specific usage requirements.
3. Testing:
   • Carry out photocell function tests by simulating the presence of an obstacle and ensuring that the gate responds correctly to detection signals.
4. Maintenance:
   • Regularly check the technical condition of the device and clean the surface of the sensors to maintain their reliability.

FAAC XP20B D photocells are an excellent choice for anyone looking for a proven and effective solution for securing automatic gates. Thanks to them, users can enjoy full comfort and safety of everyday use to secure your entrance to the property.
